The table below shows a summary of the Sense of Sensors 10 Part guide on the different types of Thermocouples. For assistance in choosing the

Thermocouple Type N: Type N (Nicrosil/Nisil) thermocouple has a Nicrosil (nickel-14%, chromium-1.5%, and silicon) positive leg, and a Nisil (nickel- 4.5%, silicon-1%, and magnesium) negative leg.

Thermocouple Type R: Types R thermocouples, (Platinum vs. 13% Rhodium/Platinum), are usable up to 1480°C (2,700°F). They are extremely stable but reducing atmospheres are particularly damaging.

Service Life Useful thermocouple life is a difficult prediction to make, even when most of the details of an application are known. And unfortunately, such

Thermocouple Type B: Platinum – 30% Rhodium (+) vs. Platinum – 6% Rhodium (-) With a general application range from 870 – 1700°C (1600 –

Thermocouple Type C: Type C (Tungsten 5% Rhenium – Tungsten 26% Rhenium) thermocouples are suited for measurements in the 0 – 2320°C (32 – 4200°F) range.

Thermocouple Type E: Type E (Chromel®/Constantan) thermocouple is composed of a positive leg of Chromel® (nickel/10% chromium) and a negative leg of Constantan (nickel/45% copper). The

Thermocouple Type J: Type J (Iron–Constantan) is a common general purpose sensor as it is one of the most linear thermocouples. Type J thermocouples have an
